16ft 5m Copper Alloy Terminal EV Charging Cable IP55 IP65 IEC Type2 to Type2
EV Cable (32A 7kW) with 16ft/5m IEC Type2 To Type2 EV Charging Model 3
This cable comes with Type 2 connectors.
Type 2 to Type 2, standard 5 metre EV Charging Cable 16Amps/32Amps. This mode 3 charging cable has a charging capacity of 16A/32A, it is ideal to charge your type 2 electric car at a maximum power of 22KW (3.2KW-22KW).
They allow you to charge yoVerdanaur car from any public or home EV charging point. It is compatible with all charging stations and all Type 2 electric and plug-in hybrid vehicles.
This cable works on all mode 3 Charging stations according to the applicable standards ISO 17409 and IEC 61851.
The Type 2 end of this cable must always be plugged directly into a charge point socket, this can not be used as an extension or an adaptor to a tethered lead.
How to start charging ?
1. Firmly insert the Type 2 male plug into the outlet socket on the AC EVSE.
2. Insert the Type 2 female plug into the inlet socket on the electric vehicle.
3. Lock your electric vehicle and the AC EVSE will charge the vehicle.
How to stop charging ?
1. Unplug the Type 2 male plug from the EVSE outlet to disconnect power.
2. Disconnect the Type 2 female plug from the vehicle inlet.
3. Put the EV charging cable away.
NOTE:
1.Please select a suitable charging current in the charging gun,the currentcannot be switched during the chargingprocess.
2.Afterthe chargingplug(car end)is disconnectedfromthe vehicle,pull outthe power plug(wall end)to preventothers from touching it.
DATASHEET
| Rated Voltage | 250V (1 Phase) /480V (3 Phases) AC |
| Frequency | 50/60Hz |
| Insulation Resistance | ＞1000MΩ |
| Insulation Resistance | ＜50K |
| Withstand Voltage | 2000V |
| Withstand Voltage | 0.5mΩ |
| Mechanical Life | ＞10000 times no-load plug in/off |
| EV Plug | IEC 62196 type 2 female plug |
| EVSE Plug | IEC 62196 type 2 male plug |
| Coupled Insertion Force | 45N～100N |
| Withstand Impact | Dropping from a 1m-height and running-over by a 2T vehicle. |
| Enclosure | Thermoplastic, flame retardant grade UL94 V-0 |
| Cable Material | TPE/ TPU |
| Enclosure | Copper alloy, silver plating |
| Ingress Protection | IP55 (unmated) IP65 (mated) |
| Certification | Certification |
| Certification Standard | IEC 62196-1/ IEC 62196-2 |
| Warranty | 1 Years |
| Working Temperature | -30℃~+50℃ |
| Working Humidity | -30℃~+50℃ |
| Working Altitude | <2000m |
Conform to the provisions and requirements of IEC 62196-2.
Using riveting pressure process with none screw, have a beautiful apprearance. Hand-held design conform to the ergonomic principle,easy plug. XLPO for cable insulation prolonging the aging resis-tance life-span,TPU shenth improved the bending life and wear.
Applied double color coating technology,customize color.
Application scenario display
The Best electric Car Charging Station products have been sold to dozens of countries, including the United Kingdom, France, Spain, and the United Arab Emirates, providing high-quality services to thousands of customers worldwide.
Factory Display
ANENGJI (CHENGDU) NEW ENERGY CO., LTD is engaged in the research, development, and manufacturing of charging station technology. As of now, the company has a range of products and technologies, including 7-44KW AC charging stations and 30-960KW DC charging stations that meet the requirements of Europe, the United States, Japan, the Middle East, and other countries. The company continues to invest in the research and development of cutting-edge technologies such as ultra-fast charging and vehicle-to-grid (V2G). The products have obtained dozens of patents as well as certifications including CE, TUV, CSA, and FCC.
